Dimension(mm)：390*310*185（L×W×H）
Weight：#
Outdoor 8 PON Ports GPON OLT
PTF3708OVirtual Headend（8 PON Ports OLTwith YEDFA）
1. Product Description
PTF3708O is designedbased on a new concept“V-HUB”.It can install GPON or EPON OLT module, WDM module and YEDFA module, can provide multi-service access, such as data and CATV. It is the new, quick and low-cost construction model for FTTX solution in bidirectional network transformation.
Two power supply andintegrates with network security, supports data, voice and video, and provides continuous forwarding, graceful restarting and ring protection, improving the work efficiency and securing the maximum running time.
Outdoor waterproof, small size and modular design, easy to install, convenient, flexible, no needspecial headend equipment room, easy to deploy high-performance broadband access network. For "triple play" applications.
2. Features
Ø XPON OLT SLOT，Support 1:128 split ratio for GPON；Support 1:64 split ratio for EPON。
Ø Integrate OLT and YEDFA in one outdoor house
Ø Built-in WDM, one fiber for triple-play
Ø Support VLAN pool, it can allocate VLAN to FTTH users automatically
Ø Support 4K VLAN based on IEEE802.1p/q
Ø Support QinQ VLAN and broadcast storm suppression
Ø Support OLTto remotelyconfigureONU
Ø Twopower supply design for redundant protection
Ø Support data encryption, multi-cast, port VLAN, separation, RSTP, etc
Ø QoS based on port, VID, TOS and MAC address
Ø SupportSNMP, telnet, CLI, OMCI/OAM and Web management,it can unified manage the OLT, ONU and EDFA modules
Ø Support opened ONU management by CTC2.1/CTC3.0 standard
|
Items |
Unit |
Specifications |
|
Chassis |
Slot |
1* XPON OLT SLOT |
|
2*Power Supply Module |
||
|
1* EYDFA Module for 8port*19dBm outputs |
||
|
1*Fiber Coiling Disc |
||
|
PON standard. |
EPON |
IEEE802.3ah |
|
GPON |
ITU-T G.98X |
|
|
10GEPON |
IEEE802.3av |
|
|
Upstream Port |
|
SFP+ optical port*2 or GE photoelectric port*2 |
|
Management Port |
|
Console serial port meet the requirement of CLI out-of-band management |
|
FE port meet the requirement of GUI out-of-band management |
||
|
10GE/GE meet the requirement of GUI in-band management |
||
|
Split ratio |
|
EPON port*8 max split ratio 1:64,Transmission distance: 20KM. |
|
Or GPON port*8 max split ratio 1:128,Transmission distance: 20KM. |
||
|
Wavelength |
nm |
Tx1490, Rx 1310 |
|
Backplane Bandwidth |
bps |
114Gbps |
|
Slot Bandwidth |
bps |
22 / 20Gbps |
|
Switch Capacity |
bps |
44Gbps |
|
MAC Capacity |
|
32K |
|
VLAN |
Basic VLAN |
Support 4K concurrent VLAN |
|
Support ACCESS and TRUNK port mode |
||
|
Support VLAN priority (COS) remark |
||
|
Flexible QINQ |
Support flexible QINQ based on report matching type (MAC/IP/CVLAN/ETH-TYPE) |
|
|
VLAN Conversion |
Support N:1 conversion based on template binding |
|
|
IGMP |
Multicast Mode |
Support SNOOPING, PROXY and CTC controllable multicast |
|
Multicast Capacity |
2K concurrent multicast groups |
|
|
Layer 3 |
|
Support statics route, max 2K statics routes |
|
Support L3 IP protocol, such as DHCP Server, DHCP Relay, DHCP Option, OSPF and RIP |
||
|
L2 Switch |
ACL |
Provide illegal frame filtering and packet filtering based on source MAC, source IP, destination IP and port. |
|
QOS |
Three strategies for queue schedule: SP (Strict Priority), WRR (Weighted Round Robin) and mix mode (SP+WRR) |
|
|
Link Aggregation |
Max 4 link aggregation groups |
|
|
Loop Detection |
Support STP and RSTP |
|
|
Efficient Configuration |
|
Support ONU configuration migration, provide batch configuration ONU template, support VLAN pool at ONU port |
|
Management |
|
Support in-band and out-of-band management |
|
Support CLI and SNMP network management |
||
|
Support batch ONU remote upgrade |
||
|
Redundant Backup |
|
Chassis OLT support redundancy hot backup of power supply, main control, upstream and PON port |
|
Link Monitor |
|
Network management supports monitoring optical link index |
|
Network management supports data flow statistics of all service ports |
||
|
Support auto alarm when link index degrades |
||
|
Operating condition |
℃ |
Operating temp: -20 ~ +65 |
|
Storing condition |
℃ |
Storing temp: -40 ~ +85 |
|
Humidity |
% |
5~90(non-condensing) |
|
Power Supply |
AC |
DC: -40V~ -57V AC:175~264V |
|
Power consumption |
W |
≤80 |
|
Dimension |
mm |
390m*310mm*185mm，（L×W×H） |
|
Net weight |
Kg |
|
