4 PON Ports GPON OLT BCM

Dimension(mm):442*220*44(L×W×H)

Weight:2.8kg

Features
Specification
Application
Video

4 PON Ports GPON OLT

PTF3704E-BCM


Overview:

PTF3704E-BCM BroadCom chipset GPON OLT provides 4 GPON ports, 2*GE+2*GE(SFP)/10GE(SFP+) uplink ports. It has high reliability, high density and powerful switching and routing abilities. It is a new generation of broadband multi-service access OLT equipment for service integrated network.
PTF3704E-BCM OLT integrates with network security, supports data, voice and video, and provides continuous forwarding, graceful restarting and ring protection, improving the work efficiency and securing the maximum running time.

1U height 19 inch rack mount product with 4 PON ports, each port supports up to 128 ONUs, the whole device supports up to 512 ONUs. Small size and high density OLT, easy to install, convenient, flexible and easy to deploy high performance broadband access network. It can be deployed in compact room environment, and can also be used for“Triple-Play”VPN, IP Camera, Enterprise LAN and ICT applications.


Features:

Ø1U 19 inch standard chassis GPON OLT with 4PON ports
ØCompliant with ITU-T G984/G.988 standards and China Telecom GPON Technical Requirements
ØFriendly EMS/Web/Telnet/CLI/SSH v1/v2 management
ØRemote online ONT configuration and management(WAN, WiFi, POTS, etc);
Ø16K Mac address
ØSupport IPv6,IPv4
ØARP proxy,1024 hardware Host Routes,512 hardware Subnet Routes;
ØSupport MLD v1/v2 snooping(Multicast Listener Discovery snooping);
ØSupport 802.1X,Radius,Tacacs+;
ØSupport 4096 VLANs, port VLAN and protocol VLAN;
ØSupport VLAN tag/Un-tag ,VLAN transparent and QinQ transmission;
ØSupport port isolation;
ØSupport port rate limitation;
ØSupport 802.1D and 802.1W;
ØSupport static LACP,Dynamic LACP;
ØQoS based on port, VID, TOS and MAC address;
ØAccess control list;
ØIEEE802.x flow control;
ØPort stability statistic and monitoring;
ØSupport IGMP snooping, 256 IP Multicast Groups
ØDHCP server,DHCP relay,DHCP snooping,DHCP option82;
ØSupport data encryption, multi-cast, port VLAN, separation, RSTP, etc
ØSupport ONT auto-discovery, auto configuration/link detection/remote upgrade of software;
ØSupport power-off alarm function, easy for link problem detection;
ØSupport broadcasting storm resistance function;
ØSupport ACL and SNMP to configure data packet filter flexibly;
ØSpecialized design for system breakdown prevention to maintain stable system;
ØSupport RSTP,IGMP Proxy;
ØSupport Dynamic Bandwidth Allocation (DBA)

ØSupport remote software upgrade,download firmware to OLT from web/tftp/ftp

Items

Unit

Specifications

PON standard.

GPON ITU-T G.984.x, G.988

PON interface

Qty.

4*GPON SFP Ports (Class C+),  Receiving sensitivity: -30dBm(Saturation Optical -12dBm). Power,Transmitting optical power: +3+7dBmTransmission distance: 20KM. Max splitting ratio1:128

Speed

Upstream 2.488G

Downstream 1.244G

Wavelength

nm

Tx1490, Rx 1310

Uplink

GE

2*GE(copper Ethernet)

SFP GE

SFP 10GE

2*GE(SFP)/10GE (SFP+) auto-detection

USB

1*USB2.0(Type A)

Layer 3

Support static route, RIP v1/v2, OSFP v2, ARP proxy

Management Ports

1*10/100BASE-T out-band port, 1*CONSOLE port

Management Mode

SNMP,Telnet,CLI,WEB,SSH v1/v2

VLAN

Tag / Un-tagVLAN transmissionQinQ

Operating condition

Operating temp: 0 ~ +50

Storing condition

Storing temp: -40 ~ +85

Humidity

%

5~90(non-condensing)

Power Supply

AC

100240V, 47/63Hz, (DC:-48V optional)

Power consumption

W

45

Dimension

mm

442*220*44L×W×H

Net weight

Kg

2.8


Shipping packaging:

Description

Quantity

Weight

Carton Size

Shipping packaging

1pcs /ctn

5kg/ctn

575*380*115mm

5pcs /ctn

25.5kg/ctn

597*402*645mm
