4G Mobile Hotspot CPE
PTW4100
Product Description:
PTW4100 4G Mobile Hotspot CPE is a high performance LTE Mobile WIFI device, with supporting all AP (Access Point) functions. Wherever in office, at home, during travelling, or on the way to somewhere, MiFi can build up the high speed Internet access freely. It supports both 4G CAT.4 and IEEE 802.11 b/g/n protocols, to equip the users enjoying the high speed internet surfing experience.
Features:
Ø 4G/3G (No 2G), Multi-mode, Multi-band, Global bands supported;
Ø Impressive brand new ID design;
Ø LTE CAT4 Technology, 150Mbps robust downlink speedrate; WIFI，300Mbps robust downlink speedrate;
Ø Wider coverage, up to 180Ms connection distance and 32 connected stations;
|
4G Data Speed Rate |
3GPP R9, CAT. 4; Downlink: 150 Mbps / Uplink: 50Mbps |
|
chip platform |
ZX297520V3E+RTL8189ES |
|
Frequent band |
PTW4100CN: FDD-LTE B1/B3/B5/B8; TDD-LTE B38/B39/B40/B41; WCDMAB1/B5/B8; PTW4100EA1: FDD-LTE B1/B3/B5/B7/B8/B20; TDD-LTE B38/B41; WCDMA B1/B5/B8; PTW4100EA2: FDD-LTE B1/B3/B5/B7/B8/B20; TDD-LTE B40; WCDMA B1/B5/B8; PTW4100SA1: FDD-LTE B2/B4/B5/B7/B28A/B28B, TDD-LTE B40; WCDMA B2/B5; PTW4100SA2: FDD-LTE B1/B3/B7/B8/B28A/B28B; TDD B40; WCDMA B1/B8; PTW4100SA3: FDD-LTE B2/B4/B5/B7/B28A/B28B/B66; TDD-LTE B40; WCDMA B2/B5 |
|
Protocol Version |
4G: 3GPP R9 Cat4 + 3G: 3GPP R7 |
|
LTE Speed |
LTE FDD: DL 150 Mbps, UL 50 Mbps |
|
Wi-Fi Standard |
802.11b:Up
to 11 Mbps |
|
Physical interface |
1*T flash, card，1*1.8V&3V 3FF (U)SIM, 1*Micro USB |
|
Battery |
2150mAh removable battery |
|
LED |
WPS/WIFI, Network,SMS,Battery |
|
Button |
POWER,Reset, WPS/WIFI |
|
Characteristic |
VPN Pass-Through Support (PPTP, L2TP & IPSec), Firewall, Local & Remote management |
|
USB I/F |
Micro USB |
|
Size |
98.2*59.6*14.1mm |
|
Weight |
74~80g |
